ORP Electrodes

Oxidation-reduction potential (ORP) is an important indicator for measuring the redox capability of a solution and has wide applications in environmental disinfection, swimming pools, biomedical water treatment, pharmaceuticals, and petrochemical production. With increasingly refined control over production processes and higher environmental protection requirements across various industries, the need for real-time and accurate pH measurement has become an inevitable demand in the era of big data.

  • Features
  • Applications
  • Specifications

High-heat engineering plastic Polyphenylene Sulfide (PPS) housing

Annular large-area Teflon Junction ensuring long-term probe stablility

Plannar or spherical glass bulb

Excellent anti-pollution and anti-clogging capability making long service time in applications

Fast response time and can be used in low conductivity waters over pH 0 to pH 14

Working temperature up to 110℃ (230oF)

Auto temperaure compensation over 0 to 110℃ (0-230oF)



Industrial Wastewater/seawater/groundwater

Aquaculture/fish farming

Environmental monitoring

Chemical and Oil Industires

Phamaceutical Process Monitoring


Measuring range: -1500mV to +1500mV

Response time: T90≤5 s;T95≤10s (25℃)

Temperature sensor: NTC 10K

Installation: Upper and lower 3/4 NPT threads

Output Digital: Modbus RS-485 signal

Measuring accuracy: ORP±0.05pH, temperature ±0.5℃
